Motor : 24VDC

Max Pull Force  : 1000 N

Max  Door Area : 15 ㎡

Transformer Power  : 175W

Max  Door Height  : 2400-3500MM

Drive Mechanism  : Belt / Chain

LimiT Setting : Electronic

Moving Speed :150MM/S

LED LIGHT : 5W/40LAMP

Radio Frequency 433.92 MHZ

Decoding:Rolling Code

Transmitter:27A 12V/CR2032 3V BATTERY

WORK Temperature:-20°C+50~°C-

Courtesy Light  3Minutes

RatedOperation Time 4 Minutes

SafetyProtection Soft  start  & Soft stop Photo cell option caution light option

Protection Level  IP20
